Questions & answers
Receptacles
The pilot contact is required for the electrical interlock. Our CEE wall-mounted receptacles, for example, are available with a pilot contact switch. This is a switch inside the receptacle that is operated by inserting and pulling out the plug. The switch ensures the electrical interlocking of the receptacles.
Cepex receptacles are used as a modular system. Regardless of whether SCHUKO®, CEE or data technology is involved: everything is accommodated by the uniform design of our Cepex receptacles across all applications.
We offer wall-mounted receptacles and receptacle combinations made of two different enclosure materials that have different properties. There is an enclosure made of high-quality plastic and another one made of special plastic, which provides protection especially against chemicals and other aggressive substances. The special plastic has a darker color to able to distinguish the plastics visually, which is the reason for the different colors.
The abbreviation HHNP stands for Highly Heat-resistant contact carriers and Nickel Plated contacts.
We would be happy to supply you with Cepex wall-mounted receptacles as a surface-mounted or flush-mounted version with a factory-fitted labeling field on request.
Plugs
The color code of a product depends on the nominal operating voltage / voltage it is designed for. Our plug ProTOP is available, for example, in the color codes red, blue, yellow, green and black. You can find an overview of the color codes here
This is theoretically possible up to 32 amperes - but a plug should never be pulled out under voltage!
The abbreviation HHNP stands for Highly Heat-resistant contact carriers and Nickel Plated contacts.
We do not offer pre-assembled cables but we can refer you to businesses that do.
No - according to the current standard, this is no longer permitted. All our plugs and sockets and receptacle combinations for camping and RV applications can be found here: Plugs and sockets for camping, Receptacle combinations for camping.
Connectors
The abbreviation HHNP stands for Highly Heat-resistant contact carriers and Nickel Plated contacts.
We do not offer pre-assembled cables but we can refer you to businesses that do.
No - according to the current standard, this is no longer permitted. All our plugs and sockets and receptacle combinations for camping and RV applications can be found here: Plugs and sockets for camping, Receptacle combinations for camping.
Dependent on the customer's flow rate specification, compressed air hoses with a nominal diameter of 9 mm or 13 mm are available. In this regard, quick-connect compressed air couplings with matching fittings are offered for the suspended power distributors.
Of course - we offer products for 160- 600 amps, usually made from aluminum or plastic. Our high-current plugs and sockets and high-current sockets can be found here. Detailed information can also be found on pages 178 to 192 of our Industrial plugs and sockets catalog.
Combinations
The approval number of our products is located inside the enclosure. For products of the AMAXX family, there is also an inspection tag in the window.
We recommend using special membrane screw connections. An installed membrane prevents ingress of external humidity. Due to the simultaneous aeration of the enclosure there is continuous equalization of ambient air and the enclosure interior air. Condensation can thus be continuously dissipated. The membrane cable gland allows introduction of connection lines without restricting aeration.
Dependent on the customer's specification, the products from various modular device manufactures can be used.
We offer wall-mounted receptacles and receptacle combinations made of two different enclosure materials that have different properties. There is an enclosure made of high-quality plastic and another one made of special plastic, which provides protection especially against chemicals and other aggressive substances. The special plastic has a darker color to able to distinguish the plastics visually, which is the reason for the different colors.
We would be happy to accommodate your wishes. Our AMAXX receptacle combinations can be flexibly configured. Please get in touch with your contact at MENNEKES. More information about the advantages of AMAXX can be found here.
Data / network technology
Cepex receptacles are used as a modular system. Regardless of whether SCHUKO®, CEE or data technology is involved: everything is accommodated by the uniform design of our Cepex receptacles across all applications.
Yes. Simply let us know which brand you prefer for data networks. Our Service department will be happy to check for you the brand to be used.
Wall mounted receptacle DUO
No, the deactivation function is a safety aspect.
PowerTOP Xtra
Our 5-pin, 16 A PowerTOP Xtra plugs and sockets are available as a PowerTOP Xtra R variant. The R stands for robust, high-heat resistant contact carriers and nickel-plated plug and connector contacts. The plug and socket device is therefore especially protected against high humidity and aggressive substances.
SCHUKO®
Cepex receptacles are used as a modular system. Regardless of whether SCHUKO®, CEE or data technology is involved: everything is accommodated by the uniform design of our Cepex receptacles across all applications.
Our panel-mounted SCHUKO® receptacles have a moulded sealing lip and require no separate seal to guarantee that protection class IP44 requirements are met.
Industry
This is a question our Service department will be able to answer on request. A generally applicable statement cannot be made in this regard due to the variety of products. Typically, our products can be used at an altitude of up to 2000 meters in accordance with the international standard DIN EN/IEC 60309 on plugs, socket-outlets and couplers for industrial purpose, which is binding for us.
7-pin plugs and sockets can be used, for example, to regulate, control and monitor devices in industry, agriculture and the trade. To this end, see also page 76-78 of our Industrial plugs and sockets catalog. Our 7-pin plugs and sockets can be found here.
Camping
No - according to the current standard, this is no longer permitted. All our plugs and sockets and receptacle combinations for camping and RV applications can be found here: Plugs and sockets for camping, Receptacle combinations for camping.
Materials
We offer wall-mounted receptacles and receptacle combinations made of two different enclosure materials that have different properties. There is an enclosure made of high-quality plastic and another one made of special plastic, which provides protection especially against chemicals and other aggressive substances. The special plastic has a darker color to able to distinguish the plastics visually, which is the reason for the different colors.
The enclosures and inserts of our popular plugs and sockets are made of the thermoplastic AMAPLAST (PC/PA), a robust engineering grade plastic which, among other qualities, offers good electrical insulation as well as being unbreakable and resistant to heat, seawater, oil and gasoline. The engineering grade thermoplastic PBT (formerly AMELAN), on the other hand, is a special plastic that we offer for the enclosures and inserts of some plugs and sockets. This plastic provides protection against chemicals and other aggressive substances such as oils, fuels, greases and alkalis. Our products with this special plastic can be used, for example, in the food and chemical industries or in refineries.
The engineering grade thermoplastic PBT (formerly AMELAN) is a special plastic that we offer for the enclosures and inserts of some plugs and sockets. This plastic provides protection against chemicals and other aggressive substances such as oils, fuels, greases and alkalis. Our products with this special plastic can be used, for example, in the food and chemical industries or in refineries.
Structural changes to plastic materials as a result of UV radiation make every type of plastic subject to ageing. Neither MENNEKES nor suppliers of plastic materials can guarantee perfect resistance to UV radiation of plastic materials. We have experienced product lifetimes of 20 years and more with outdoor applications of our products. We are not in a position to specify a minimum service life for our products since they are exposed to a number of different situations during normal use and especially mechanical wear.
Contact sleeves
The abbreviation HHNP stands for Highly Heat-resistant contact carriers and Nickel Plated contacts.
Norms and Regulations
The color code of a product depends on the nominal operating voltage / voltage it is designed for. Our plug ProTOP is available, for example, in the color codes red, blue, yellow, green and black. You can find an overview of the color codes here
This is a question our Service department will be able to answer on request. A generally applicable statement cannot be made in this regard due to the variety of products. Typically, our products can be used at an altitude of up to 2000 meters in accordance with the international standard DIN EN/IEC 60309 on plugs, socket-outlets and couplers for industrial purpose, which is binding for us.
Rising temperatures can result in the formation of condensation in receptacle combinations. Special membrane screw connections for protection type IP67 enclosures ensure an exchange of air and prevent evaporation. In practical application, feeding from below has proven to be effective.
The clock position indicates the position of the protective earth (PE) conductor contact on the live end. More information can be found here
The products of our EverGUM family fulfil the requirements for protection type IP44 as standard. We would be happy to check whether we could equip an EverGUM product so that it meets the requirements for another protection type as a special solution.
Connection technologies
ErgoCONTACT refers to a specially enhanced, innovative, easy-to-use screw-contact technology that is available for plugs and sockets. It enables easy, secure, and time-saving installation. To this end, the screwdriver is inserted from the top instead of the side to apply pressure directly against the handle. The screw is additionally guided by a collar. This prevents it from slipping and minimizes the risk of injuries. Each contact has only one screw: a captive combination head screw that is integrated in the guide collar and can be turned using either a Phillips or flathead screwdriver. More information can be found here.
We are offering screwless connection techniques for up to 32-amp wall-mounted receptacles, panel-mounted receptacles, and plugs and connectors. Look for “SafeCONTACT” and “TwinCONTACT”..
General
Address:
MENNEKES Elektrotechnik GmbH & Co. KG
Industriestraße 2
Welschen-Ennest
D-57399 Kirchhundem
Pick-up hours:
Monday to Friday
7.00 am to 12.15 pm and 12.45 pm to 2.00 pm
Please ask your contact in the ordering department beforehand if your products are ready for pick-up.
Contact: vi@mennekes.de
Important information on picking up pallets:
Please keep in mind that pallets can only be loaded from the rear via our loading dock. A forklift cannot be used for loading.
Furthermore, we would like to point out that the person picking up the product(s) is responsible for ensuring that the load is secured in the vehicle.
Yes, spare parts are available for all of our products. Tell your contact at MENNEKES the part number of the product for which you need a spare part.
Our products have various IK values. Your contact at MENNEKES will be happy to tell you the IK value for the specific part number.
Please do not make any unauthorised deductions on your own.
Please send your debit note to vi@MENNEKES.de
Please state the reason and/or the basis for the debit (quotation number, old reference number, etc.), as well as your reference details (order number or invoice number)
MENNEKES uses a multistage distribution channel for selling products.
- Purchase as end customer: through an electrical installation specialist of your choice
- Purchase as electrical specialist: through an electrical wholesaler of your choice
- Purchase as electrical wholesaler: online using EDI; in exceptional cases by e-mail to vi@MENNEKES.de or by fax to +49 2723 41-300
- As end customer, please contact your wholesaler for inventory inquiries
- Please send order changes / cancellation requests to vi@MENNEKES.de stating order no., part no. and order date
- Orders are placed in compliance with our General Terms and Conditions
Industrial plugs and sockets
For products of our product range, you can download the declarations of conformity from the respective product pages, or you can request them. If it is a new receptacle combination that was customised to the needs of the customer, a declaration of conformity will only be available after the order has been received and the first device has been produced.
Downloads
Yes. A data sheet is available for download for each standard receptacle combination on the product detail page. For customer-specific solutions, a schematic diagram and an electric circuit diagram are included in the product text.
On the corresponding product detail pages on our website, we offer STEP files for download on some products. STEP files of the remaining articles are available on request.
Most of the technical documents are available for download from our website.
Various certificates, including the DIN ISO certificates, can be found here:
All of the other technical documents are available as follows:
- In the search field on the start page, enter the part number of the product
- Another window opens displaying the respective part number.
- Click on the product
- You can select and download the corresponding document from this page
- In addition, relevant files are also available directly on the website of the respective wholesaler
All other certificates, approvals, data and/or certifications are available on request at: vi@MENNEKES.de
