MENNEKES Panel mounted receptacle SCHUKO® 11311
MENNEKES Panel mounted receptacle SCHUKO® 11311 images3d

Panel mounted receptacle SCHUKO® 11311

Ampere 16 A
Poles
Voltage
  • for portable use
  • with front gasket
  • with hinged lid
  • 3 plug-in terminals as connecting terminals for 1.5 – 2.5 mm²
  • other colours on request
  • Part no.11311
  • EAN4015394257677
  • Std. Pack. 100

Technical specifications

Panel mounted receptacle SCHUKO® 11311

Ampere 16 A
Poles 2 p+PE
Voltage 230 V
Connection technology Plug-in terminals
Contact standard
Protection type IP54
Shutter No
Flange 50x50 mm
Fixing hole 38x38 mm
Weight 58 g
Certifications VDE

Datasheets & Downloads

Panel mounted receptacle SCHUKO® 11311

Product infoPanel mounted receptacle SCHUKO® 11311 PDF, 112 KB
Dimensional drawing portraitPanel mounted receptacle SCHUKO® 11311 PNG, 39 KB
Dimensional drawing landscape formatPanel mounted receptacle SCHUKO® 11311 PNG, 53 KB

Directives

Panel mounted receptacle SCHUKO® 11311

REACh
RoHS

Appropriate accessories

Panel mounted receptacle SCHUKO® 11311

MENNEKES Fixing frame 19266106

Fixing frame

Part no. 19266106

for swift and safe fastening of panel mounted receptacles

more
MENNEKES Blanking flange 41418

Blanking flange

Part no. 41418

to close unused apertures, grey

more
