MENNEKES Panel mounted receptacle SCHUKO® 11032

Panel mounted receptacle SCHUKO® 11032

Ampere 16 A
  • for stationary use
  • with hinged lid
  • 3 screw terminals as connecting terminals for 1.5 – 2.5 mm²
  • Part no.11032
  • EAN4015394184638
  • Std. Pack. 100

Technical specifications

Panel mounted receptacle SCHUKO® 11032

Ampere 16 A
Poles 2 p+PE
Voltage 230 V
Connection technology Screw terminals
Contact standard
Protection type IP54
Shutter No
Flange 50x50 mm
Fixing hole 38x38 mm
Weight 47 g
Certifications VDE

Directives

Panel mounted receptacle SCHUKO® 11032

Appropriate accessories

Panel mounted receptacle SCHUKO® 11032

MENNEKES Base for wall mounted receptacle 10715

Base for wall mounted receptacle

Part no. 10715

with cable entry and screws, suitable for all panel mounted receptacles SCHUKO®/ grounding type receptacles, flange: 50 x 50 mm

MENNEKES Base for wall mounted receptacle 10714

Base for wall mounted receptacle

Part no. 10714

with cable entry and screws, suitable for all panel mounted receptacles SCHUKO®/ grounding type receptacles, flange: 50 x 50 mm

MENNEKES Base for wall mounted receptacle 10716

Base for wall mounted receptacle

Part no. 10716

with cable entry and screws, suitable for all panel mounted receptacles SCHUKO®/ grounding type receptacles, flange: 50 x 50 mm
